ELECTRICITY REQUIREMENTS
IMPORTANT! REFER TO LOCAL CODE REQUIREMENTS BEFORE WIRING MACHINES.
ALL MACHINES REQUIRE:
The power source must be grounded
Frequency range is 47-66 Hz
Line voltage that does not fluctuate more than +/-5%
Voltage imbalance or no more than 2%
Harmonic distortion is not to exceed 10% of the total RMS voltage
Voltage Requirements
Mini Mill 208 3PH / 240V 1PH ±10%
Power Supply 40 AMP
Haas Circuit Breaker 40 AMP
If service run from elec. panel
is less than 100' use: 1PH - 8 GA WIRE / 3PH - 10 GA WIRE
If service run from elec. panel
is more than 100' use: 1PH - 6 GA WIRE / 3PH - 8 GA WIRE
WARNING!
A separate earth ground wire of the same conductor size as the input power is required to be connected to
the chassis of the machine. This ground wire is required for operator safety and for proper operation. This
ground must be supplied from the main plant ground at the service entrance, and should be routed in the
same conduit as the input power to the machine. A local cold water pipe, or ground rod adjacent to the
machine cannot be used for this purpose.
Input power to the machine must be grounded. The machine will not function properly on ungrounded power.
The maximum voltage leg-to-leg or leg-to-ground should not exceed 260 volts.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Haas Mini Mill and is the answer not in the manual?

Haas Mini Mill Specifications

General IconGeneral
Spindle Speed6, 000 rpm
X Axis Travel406 mm (16 in)
Y Axis Travel305 mm (12 in)
Z Axis Travel254 mm (10 in)
Spindle Power5.6 kW (7.5 hp)
Tool Capacity10 tools
Table Size914 mm x 305 mm (36 in x 12 in)
Spindle TaperCT40
Rapid Traverse X Axis15.2 m/min (600 in/min)
Rapid Traverse Y Axis15.2 m/min (600 in/min)
Rapid Traverse Z Axis15.2 m/min (600 in/min)
