Haas VF-3 User Manual

Assembly Drawings
June 1999
529
96-8000
30-1220A Coupling Assembly
ITEM QTY PART No. TITLE
1 1 20-7403 COUPLING, SERVO DRIVE
20-76152 1 COUPLER, BRUSHLESS
51-201423 BEARING LOCKNUT, CL18F
59-2060
56-006542
51
SNAP RING, (5100-112)
FLEXPAK FOR AJ05
BS ASSY 32mm(1.26) x 35.65
30-0194
WHERE USED
BS ASSY 32mm(1.26) x 33.27
BS ASSY 32mm(1.26) x 48.23
BS ASSY 32mm(1.26) x 25.65
30-0617
30-0615
30-0451
APPLICATION
SL20 (Z)
SL30 (Z)
SL40 (X)
VF-0EB, 2B (X)
BS ASSY 32mm(1.26) x 48.23
30-0195
VF-3B, (X) (Z)
BS ASSY 32mm(1.26) X 33.27
30-0196
VF-3B, 4B, SL20 (Y) (Z), HS-1/RP
BS ASSY 32mm(1.26) x 58.47
VF-4B (X)
BS ASSY 32mm(1.26) x 13.53
SL20 (X)
30-0197
30-0616
30-0618
SL30 (X)
BS ASSY 32mm(1.26) x 16.78
BS ASSY 32mm(1.26) x 25.65
30-0157
SL40, VF-1,2,O
