60
INSTALLATION
June 1999
96-8000
SHIPPING THE MACHINE WITHOUT A PALLET
To ship a VMC a short distance, it may not be necessary to mount it on a pallet and crate if you
employ professional machinery movers. Nevertheless, you must make specific preparations for
moving it and certain precautions are necessary.
NOTE: We strongly recommend using an air-ride suspension truck to minimize
jarring the machine. It is well worth the few extra dollars involved. And make
sure to ask specifically for air-ride suspension -- not all riggers have trucks of
this type.
IMPORTANT!
1. All of the warnings and cautions in the previous sections of this manual apply to shipping without a
pallet review them carefully.
2. Parts of an unprotected VMC can be damaged by heavy tarps, indiscriminate use of tie-downs,
etc. Therefore, it must be shipped in accordance with the following outlines.
TOOLS REQUIRED
9/16" Hex Wrench
¾" Wrench (Open-end or Box-end)
Forklift with the following specifications:
E/O-FV TXE/EO-FV 1-FV 2-FV 3-FV 4-FV 04/5-FV
*thgieWenihcaM000,7009,7001,7000,8005,21000,31005,41
htgneLkroF'8'8'8'8'8'8'8
05/5-FV6-FV7-FV8-FV9-FV01-FV11-FV
*thgieWenihcaM006,41001,2000,32000,42000,52000,82004,92
htgneLkroF'8'8'8'8'8'8'8
* The forklift must be capable of lifting at least this weight.
MATERIALS REQUIRED
Four metal tie-downs
Four ¾-11 nuts (in addition to the four nuts that come with the machine)
Two 4 x 4's at least 5' long
