293
PARAMETERS
June 1999
96-8000
Parameter 228 QUICKCODE FILE
This parameter set the program numbers to store in the Quick Code definition program.
Usually, this is 9999.
Parameter 229 X LEAD COMP 10E9
This parameter sets the X-axis lead screw compensation signed parts per billion.
Parameter 230 Y LEAD COMP 10E9
This parameter sets the Y-axis lead screw compensation signed parts per billion.
Parameter 231 Z LEAD COMP 10E9
This parameter sets the Z-axis lead screw compensation signed parts per billion.
Parameter 232 A LEAD COMP 10E9
This parameter sets the A-axis lead screw compensation signed parts per billion.
Parameter 233 B LEAD COMP 10E9
This parameter sets the B-axis lead screw compensation signed parts per billion.
Parameter 235 TSC PISTON SEAT
With the 50 TSC option, the amount of time given for the piston to seat during system start-up.
The default is 500 milliseconds. If machine has a 50 Taper spindle and the TSC option, this
parameter must be set to 0.
Parameter 236 TSC LOW PR FLT
After the TSC system has stabilized following startup, Alarm 151 is generated if coolant
pressure falls below 40 psi for the amount of time set in this parameter. The default is 1000
milliseconds.
Parameter 237 TSC CLNT LINE PURGE
The amount of time given for the coolant to purge when the TSC system is shut off. This
parameter may be increased by the user to a higher value to help purge coolant from small
orifice tooling. The minimum (default) value is 2500 milliseconds.
Parameter 238 MAX TSC SPINDLE RPM
When TSC is enabled and in use, this parameter limits the maximum spindle speed. Default
value is 7500 RPM. On 50 taper machines, TSC can be run at the maximum speed of 5000
RPM
Parameter 239 SPNDL ENC STEPS/REV
This parameter sets the number of encoder steps per revolution of the spindle encoder.
Parameter 240 1ST AUX MAX TRAVEL
This parameter sets the maximum travel of the first auxillary (C) axis in the positive direction.
Parameter 241 2ND AUX MAX TRAVEL
This parameter sets the maximum travel of the second auxillary (U) axis in the positive
direction.
