Hach AF7000 - Page 19

Replace the fuses
D A N G E R
Fire hazard. Use the same type and current rating to replace fuses.
The instrument has fuses in two locations. Figure 5 shows the location of the 5 A fuses. Figure 6
shows the location of the 8 A fuses.
Figure 5 Fuse location, 5 A
English 19
