If this is not observed it may damage the chain feed-in.
6.5 Tools
7 Operation
Only people that are familiar with the operation of the lifting devices and cranes may be entrusted with their
operation. They must be authorized by the employer for the operation of the equipment. The employer must
ensure that the operating instructions are available near the equipment and that they are accessible for the
operating personnel.
The shown control switches are only for the optical information. They can be different acc. the delivery.
Pendant control lifting/lowering
direct control
1 Emergency-Stop
2 Lifting (slow - fast)
3 Lowering (slow - fast)
Illustration 5
Pendant control – 4 push buttons
1 Emergency stop
2 Selection switch (as option)
3 Lifting (slow - fast)
4 Lowering (slow - fast)
5 Trolley travel right side (slow - fast)
6 Trolley travel left side (slow - fast)
Illustration 6
Tool Use
Load bar
