Chapter 2, Machine Part Replacement Reference 2-7
Blood Line Air Detector
1. Remove the front and rear panels. (See page 2-2.)
2. Remove blood pump assembly for easier access. (See page 2-10.)
3. Disconnect P606 from the top deck distribution board.
4. Remove the (2) Phillips head screws securing the air detector to the
top deck.
5. Firmly press the air detector head (from the top) through the top deck.
This is a very tight fit.
Note: See the following reassembly notes.
A
C and Blood Line Air Detector Reassembly Notes
1. Apply a light film of silicone vacuum grease to the air detector
grommet before attempting to install the air detector.
2. If both top deck air detectors are removed, be sure to return the
correct air detectors to the correct locations. The plugs are keyed, so
use the descriptions on the top deck distribution board for
identification. P605 is for the AC and P606 is for the Blood Line Air
Detector.
3. LED is located toward the front of unit.
Line Sensor
1. Remove the rear panel. (See page 2-2.)
2. Disconnect P607 from the top deck distribution board.
3. Remove the (2) Phillips head screws securing the line sensor to the
top deck.
Note: It may be necessary to use a ratchet or stubby screwdriver to access
these screws. If you still have trouble, you may have to slide the
card cage back.
Line Sensor Reassemb
ly Notes
1. Be sure the line sensor gasket is in place between the sensor and the
top deck before securing.
2. Calibrate the line sensor. Refer to the procedure in Chapter 4, Calibration.
Top Deck Distribution Board
1. Remove the front and rear panels. (See page 2-2.)
2. Remove the centrifuge. (See page 2-12.)
3. Remove the pumps. (See page 2-10.)
4. Remove or slide back the card cage (See page 2-4.)
