Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0
30
SETUP & PROGRAMMING
OPTION 7. Set Number of Output Cards
OPTION 8. Inhibit Muted Tone Beeps
Up to 2 output/relay cards may be added to each control panel to provide additional common or zonal
outputs. The presence of the cards must be setup to enable operation.
With the zone 7 fi re LED lit, the amber, fault LEDs (zones 1 - 2) will show the current settings.
Zone 1 amber fault LED ON = Output Card 1, Zone 2 = Output Card 2.
Press the ENTER button, zone 1 fi re LED will pulse to indicate adding or removing card 1.
Use buttons 1 & 3 (1=forward, 3=backward) to move the pulsing fi re LED to the required zone (Cards 1 - 2
indicated by zones 1 & 2 respectively).
Then use button 2 to add or remove the card, indicated by the amber fault LED ON (added) or OFF
(removed).
Option to inhibit the intermittant beep that still occurs when a fault or fi re tone has been muted using the
Mute Buzzer button.
With the zone 8 fi re LED lit, Press the ENTER button. The zone 1 fi re LED will pulse ‘edit mode’.
Press button 1 to light the zone 1 fault LED. Beeps are now silenced.
When fi nished press the ENTER button again and the zone 7 fi re LED will return to steady ‘view mode’.
Press button 1 to move to next option or hold button 1 for 3 seconds to exit programming mode 2-1-2-3.
When fi nished press the ENTER button again and the zone 8 fi re LED will return to steady ‘view mode’.
Press button 1 to move to next option or hold button 1 for 3 seconds to exit programming mode 2-1-2-3.
OPTION 9. Inhibit Network Alarms & Faults For Panel
This option prevents any other network panel’s alarms or faults from displaying or having any effect on the
panel.
The default setting is ON (panel displays all network alarms & faults and the outputs respond accordingly).
If set to OFF, alarms & faults from other network panels will be ignored. Fires & faults from this panel will
still affect other network panels accordingly.
With the zone 9 fi re LED lit, Press the ENTER button. The zone 9 fi re LED will pulse ‘edit mode’.
The zone 9 fault LED will be lit (indicates network alarms & faults active).
Press button 1 to change the fault LED to OFF (network alarms & faults inhibited).
When fi nished press the ENTER button again and the zone 9 fi re LED will return to steady ‘view mode’.
Press button 1 to move to next option or hold button 1 for 3 seconds to exit programming mode 2-1-2-3.
