Excel-EN Installation, Commissioning & Operating Manual Approved Document Ref: UI-XLEN-01 Issue 7.0
37
SETUP & PROGRAMMING
2
2
2
1
1
1
2
1
3
4
4
4
Dependency Mode Selection
Select Zones For Dependency Mode
Set Timings For Dependency Mode B
To change the dependency mode type for the panel, enter the above code and press ENTER (panel is set
to type A by default).
The amber, fault LED 1 will pulse and the current setting will be indicated by a steady amber, fault LED as
per table below.
To select which zones should be included in the dependency mode, enter the above code and press
ENTER.
The amber, fault LED 1 will pulse and any zones that are currently set to dependency mode will be indicated
by a steady amber, fault LED.
Use button 1 to move the pulsing amber LED to the required zone(s) for setting and press ENTER to select.
The LED will change to a rapid pulse to indicate that the zone is now set to dependency mode. Pressing
ENTER again will de-select the zone and the LED will change back to a slow pulse.
Press and hold button 1 for 3 seconds to save the settings and exit the programming mode.
There are two programmable timings for dependency mode B, the confi rmation time
1
, and the auto reset
time
2
.
Enter the above code and press ENTER. The fi re LED 1 will light indicating changing the timing for the
confi rmation time, 1 - 4 minutes. Use button 1 to move to fi re LED 2, for changing the timing for the auto
reset time (5 - 30 minutes). A third press of button 1 will light fi re LED 3 which is for changing Twin Wire
detector compatibility (see over page), and then back to 1 again.
With the required fi re LED lit, the amber, fault LEDs will indicate the current timings set. Press the ENTER
button to enter ‘edit mode’ and the fi re LED will change to pulsing.
Now use buttons 1 & 3 to increase or decrease the time. Button 1 increases, button 3 decreases. When
fi nished press ENTER again to return to ‘view mode’
The confi rmation time
1
is indicated by the amber, fault LEDs 1 - 4 (1 - 4 minutes).
The auto reset time
2
is indicated by the amber, fault LEDs 1 - 5 using binary code values. See table below.
Each push will increase or decrease the time by 1 minute.
Use button 1 to move the pulsing amber LED to the required type as per above and press ENTER to select
it. The LED will change to a rapid pulse to indicate that it is now the current setting.
Press and hold button 1 for 3 seconds to save the setting and exit the programming mode.
LED 1 LED 2 LED 3 LED 4
No Dependency Mode Type A Type B Type C
AMBER LED 1 AMBER LED 2 AMBER LED 3 AMBER LED 4 AMBER LED 5
1 Minute 2 Minutes 4 Minutes 8 Minutes 16 Minutes
