DE
Einbaumaße für Abdeckung,
aufgesetzt / von außen
Rechte Abdeckung am Bauteilkörper
Schrankkörper
22 mm
Riegel (Kämm)
27 mm
42 mm
62 mm
3 mm
Lochdurchmesser
4 mm
Lochdurchmesser
16 mm
7
