EN
Mounting on Left & Right Door
RIGHT LEFT
Hinges on
outside of
door are on
the Right
Hinges on
outside of
door are on
the Left
Peg on stop cam
is on the right side
Peg on stop cam
is on the left side
Back View
Knob, rotates to the
right to open lock
Back View
Knob, rotates to the
left to open lock
View of the lock
in closed position
