14 . Information of Resistors and Capacitors
CAPACITORS
RESISTORS & CAPACITORS-PARTS NO.CODE
Notes:
1.part numbers are indicated on most mechanical parts.
Please use this part number for parts orders.
2.The unit of resistance is (ohm).K=1000 ,M=1000K
3.The unit of capacitance is F(microfarad). 1pF=10
-6
F.
Numbering system of Capacitor
Example
CL42 ----- 17 ---- 50V ---- 2F4 ---- 104 * ---- Z
Type Voltage Value (pF) Tolerance
CL21X ---- 100V ---- 223 * ---- J
Type Voltage Value (pF) Tolerance
CL110X ---- 25V ---- 100 F 20%
Type Voltage Value Tolerance
* 104 =10 10
4
223=22 10
3
Numbering system of resistor
Example
RY17S ---- 2W ---- 390 ---- J ---- 05-E-A
Type Wattage Value( ) Tolerance
RS11 ---- 1/2W ---- 1.8K ---- K
Type Wattage Value Tolerance
ABBREVIATION OF PART NAME AND DESCRIPTION
RESISTOR CAPACITOR
PART NAME & DESCRIPTION
TYPE ALLOWANCE
T
Carbon
F
1%
S
Solid
J
5%
J
Metal
K
10%
Y
Oxide
M
20%
F
Fuse
G
2%
PART NAME & DESCRIPTION
TYPE ALLOWANCE
C
Ceramic
J
5%
T
Ceramic
K
10%
L
Film
L
15%
D
Electrolytic
M
20%
A Tantalum P +100%-0%
Z +80%-0%
