3-3. Power Board
3-3-1 Function Description:
Supply power for Main board, Panel.
&RQQHFWRUGH¿QLWLRQ
Service Manual
Model No.:
- 11 -
CON4
Pin number Signal name
1
GND
2
GND
3
4 +5V
5 POWER ON/OFF
6 +5VSTB
7 +5V
8 +5V
9 GND
10 GND
11 GND
12 +12V
13 +12V
NC
