Service Manual
Model No.:
- 13 -
3-4-1.Connector de finition
Connector : FI-RE51S-HF (JAE/UJU)
Pin Symbol Description Pin Symbol Description
1 NC NOTE1 26 NC NOTE1
2 NC NOTE1 27 NC NOTE1
3 NC NOTE1 28 Rx2[A]N Even LVDS Signal -
4 NC NOTE1 29 Rx2[A]P Even LVDS Signal +
5 NC NOTE1 30 Rx2[B]N Even LVDS Signal -
6 NC NOTE1 31 Rx2[B]P Even LVDS Signal +
7 NC NOTE1 32 Rx2[C]N Even LVDS Signal -
8 NC NOTE1 33 Rx2[C]P Even LVDS Signal +
9 NC NOTE1 34 GND Ground
10 NC NOTE1 35 Rx2CLK- LVDS Clock -
11 GND Ground 36 Rx2CLK+ LVDS Clock +
12 Rx1[A]N Odd LVDS Signal - 37 GND Ground
13 Rx1[A]P Odd LVDS Signal + 38 Rx2[D]N Even LVDS Signal -
14 Rx1[B]N Odd LVDS Signal - 39 Rx2[D]P Even LVDS Signal +
15 Rx1[B]P Odd LVDS Signal + 40 Rx2[E]N (Note 2) Even LVDS Signal -
16 Rx1[C]N Odd LVDS Signal - 41 Rx2[E]P (Note 2) Even LVDS Signal +
17 Rx1[C]P Odd LVDS Signal + 42 NC NOTE1
18 GND Ground 43 NC NOTE1
19 Rx1CLK- LVDS Clock - 44 GND Ground
20 Rx1CLK+ LVDS Clock + 45 GND Ground
21 GND Ground 46 GND Ground
22 Rx1[D]N Odd LVDS Signal - 47 NC NOTE1
23 Rx1[D]P Odd LVDS Signal + 48
12V DC power supply
24 Rx1[E]N (Note 2) Odd LVDS Signal - 49
12V DC power supply
25 Rx1[E]P (Note 2) Odd LVDS Signal + 50
12V DC power supply
51
12V DC power supply
To Next Page
