Service Manual
Model No.:
- 07 -
6SHFL¿FDWLRQV
Model 48D3500
Screen Size 48 inch
Aspect Ratio 16:9
Resolution 1920*1080
Response Time (ms)
8.0 (GRAY TO
GRAY)
Angel of View 176o
Color Display16.7M
No. of Preset Channels
OSD LanguageEnglish
Color System NTSC
Audio System DK, BG, I, M, L, L'
Audio Output Power
(Built-in) (W)
10W×2
Audio Output Power
(outer) (W)
No
Total Power Input (W) 72W
Voltage Rang
e (V)
Power Frequency (Hz) 50~60Hz
Net Weight (KG) 12.8
Gross Weight (KG) 15.8
Net Dimension (MM) 1073*78*645mm
Packaged Dimension
(MM)
1073*280*703mm
AC 100-240V
Cable :1-135
Air: 2-69 (ATV&DTV)
