4.2 Specication
Item Model AP48KS1ERA(S)/1U48IS1EAB(S)
Function
cooling heating
Capacity
kW 14.5 15.6
Sensible heat ratio
0.74
Total power input
kW 4.51 4.57
Max. power input
W 6500 6500
EER or COP
W/W 3.22(A) 3.41(B)
Dehumidifying capacity
10
‐
³×m³/h 5.1
Power cable
/
Power source
N, V, Hz 1, 220~230, 50
Running /Max.Running current
A / A 8.3/10.5 8.4/10.5
Start Current
A /
Indoor
unit
Unit model (color)
AP48KS1ERA(S)
Fan
Type × Number
CENTRIFUGALX1
Speed(H-M-L)
r/min 460/430/400±40
Fan motor input power
kW 0.20
Fan motor output power
kW 0.09
Air-ow(H-M-L)
m³/h 1750/1500/1350
Heat
exchanger
Type / Diameter
mm inner grooved pipe/φ7.0
Total area
m² /
Dimension
External
（
L×W×H
）
mm×mm×mm 1850×600×350
Package
（
L×W×H
）
mm×mm×mm 1980×660×420
Drainage pipe (material , I.D./O.D.)
mm /
Controller (O-Optional,S-Standard)
Wired YR-E16(O)/YR-E17(O)
Infrared YR-HD01(S)
Fresh air hole dimension
mm /
Electricity heater
kW 0
Sound power Noise level (H-M-L)
dB(A) 69
Sound pressure Noise level (H-M-L)
dB(A) 51/48/44
Weight (Net / Shipping)
kg / kg 57/65
Piping
Refrigerant
Type / Charge
g R410A/2850
Recharge quantity
g/m 45
Pipe
Liquid
mm 9.52
Gas
mm 19.05
Between I.D
&O.D
MAX.Drop
m 30
MAX.Piping length
m 50
Norminal condition: indoor temperature (cooling): 27
℃
DB/19
℃
WB, indoor temperature (heating): 20
℃
DB
Outdoor temperature(cooling): 35
℃
DB/24
℃
WB, outdoor temperature(heating): 7
℃
DB/6
℃
WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser
calibrated sound intensity meter. It is a sound pressure noise level.
