Indoor Unit
103
Super Match
3.2 Specication
Item Model AD09SS1ERA
Function —— Cooling Heating
Capacity W 2700 2800
Sensible heat ratio W 0.71 /
Dehumidifying capacity 10-³xm³/h 1.0
Indoor unit
Power supply 1PH, 220-230V~, 50/60Hz
Fan
Type × Number —— centrifugal*1
Speed(H-M-L) r/min 850/750/650
Fan motor output/input power W 11/15
Air-ows (H/M/L) m³/h 530/460/390
Heat exchanger
Type / Diameter mm inner grooved pipe/
￠
7.0
Row —— 2
Total area m² 0.11
Temp. scope
℃
2.0-7.0
Dimension
(LxWxH)
External mmxmmxmm 850x420x185
Package mmxmmxmm 1045x540x270
Drainage pipe (material,I.D/O.D) mm PVC 27/31
Control type(Remote/Wired) Remote or Wired
Fresh air hole dimension mm none
Electricity heater kW none
Noise level(H-M-L)
Sound power level dB(A) 43/39/36
Sound pressure level dB(A) 33/29/26
Controller
(O-Optional,S-Standard)
Wired YR-E17(S )/YR-E16A(O)
Infared YR-HD01(O)
Weight(Net/Shipping) kg/kg 15.9/20.6(with water pump:16.7/21.4)
Piping
Refrigerant Type R410A
Pipe
Liquid mm Φ6.35(1/4)
Gas mm Φ9.52(3/8)
Connecting method Flared
Norminal condition: indoor temperature (cooling): 27
℃
DB/19
℃
WB, indoor temperature (heating): 20
℃
DB
Outdoor temperature(cooling): 35
℃
DB/24
℃
WB, outdoor temperature(heating): 7
℃
DB/6
℃
WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity meter. It is a
sound pressure noise level.
