Haier AB18CS1ERA - Air Velocity and Temperature Distribution

Indoor Unit
73
Super Match
2.5 Air velocity and temperature distribution
A)On the floor
a. Cooling / Air Velocity Distribution
Coolin g
Blow y angle:2 5
Ai r Velocit y Distributio n
1.5m/s
1.0m/s
0.5m/s
2.4m
0 m
5.5 m
b. Cooling / Temperature Distribution
Coolin g
Blow y angle:2 5
Temperatur e Distributio n
22
25
27
2.4m
0 m
5.5 m
AC12CS1ERA(S) AC18CS1ERA(S) AC24CS1ERA(S) AC28ES1ERA(S) AC36ES1ERA(S)
