Haier AB18CS1ERA - Page 222

220
Super Match
Item Model 1U28HS1ERA(S)
Power cable H05RN-F 3G 6.0mm2
Communication cable/Connecting cable H05RN-F 4G 2.5mm2
Power source N, V, Hz 1PH, 220-230V~, 50/60Hz
Start current A 4
Outdoor
unit
Unit model (color) 1U28HS1ERA(S)
（
WHITE
）
Compressor
Model / Manufacture/Place TNB220FLHMC-L / MELCOM
OIL model FV50S
Oil charging 870CC
Type Twin Rotary
Fan
Type × Number axial×1
Speed r/min High 860
Fan motor output /input power W 100/130
Air-ow(H-M-L) m³/h 3500
Heat exchanger
Type / Diameter mm TP2M/Φ7.0
Row/ Fin pitch 2
1.4
Total area m² /
Dimension
External
（
L×W×H
）
mm×mm×mm 948/340/840
Package
（
L×W×H
）
mm×mm×mm 1040/1000/430
Drainage pipe (material , I.D./O.D.) mm none
Refrigerant control method mm/mm EEV 2.2mm
Defrosting auto
Volume of accumulator L none
Sound power noise level (H-M-L) dB(A) 70
Sound pressure noise level (H-M-L) dB(A) 58
Type of four way valve SHF-9H-35U
material of reduce noise felt
crankcase heater power W /
Weight(Net / Shipping) kg / kg 64/73
Piping
Refrigerant
Type / Charge g R410A/2450
Maximum pipe length without
recharge refrigerant
m 20
Recharge quantity g/m 45
Pipe
Liquid mm 9.52
Gas mm 15.88
Connecting Method Flared
Between I.D
&O.D
MAX.Drop m 20
MAX.Piping length m 30
Working
temp.
Cooling(Min-Max)
℃
-10
～
46
Heating(Min-Max)
℃
-15
～
24
Norminal condition: indoor temperature (cooling): 27
℃
DB/19
℃
WB, indoor temperature (heating): 20
℃
DB
Outdoor temperature(cooling): 35
℃
DB/24
℃
WB, outdoor temperature(heating): 7
℃
DB/6
℃
WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity
meter. It is a sound pressure noise level.
