252
Super Match
5U34HS1ERA 5U45LS1ERA:
If this outdoor unit connects with AS*S1ERA, the connecting cable is 1.5mm²
Connect the connecting wires between indoor and outdoor units and ensure the sequence numbers on
terminals match with each other.
••••••
Power Supply Cable:
H05RN-F3G 4.0mm²
Connecting Cable:
H05RN-F4G 2.5mm²
Connecting Cable:
H05RN-F2G 2.5mm²
