Single Split
3
Outdoor unit
Unit model (color)
1U48IN1EAB
Compressor
Model / Manufacture
ATE518SC3Q9RKA/Shanghai Hitachi
Elctrical Appliances Co.,Ltd
Oil model
α68HES-H
Oil type
α68HES-H
Oil charging
1600ml
Type
Rotary
Protection type
Inner thermal protection
Starting method
direct start
Fan
Type × Number
axial×2
Speed r/min
840±30/520±40
Fan motor output power kW
0.07
Air-ow(H-M-L) m³/h 6500
Heat exchanger
Type / Diameter mm
TP2U/Φ9.52
Row / Fin pitch
2/1.75
Dimension
External
（
L×W×H
）
mm×mm×mm
960×340×1250
Package
（
L×W×H
）
mm×mm×mm
1095×410×1400
Drainage pipe (material , I.D./O.D.) mm
none
Refrigerant control method mm/mm
capillary
Defrosting
auto
Volume of Accumulator L 3
Noise level dB(A)
58
Type of Four way valve
DSF-20
material of reduce noise
XPE
crankcase heater power W
40
PIPING
Refrigerant
Type / Charge g
R410A/3400
Recharge quantity g/m
65
Pipe
Liquid mm
φ9.52
Gas mm
φ19.05
Connecting Method
Flared
Between I.D
&O.D
MAX.Drop m
20
MAX.Piping length m
30
Norminal condition: indoor temperature (cooling): 27
℃
DB/19
℃
WB, indoor temperature (heating): 20
℃
DB
Outdoor temperature(cooling): 35
℃
DB/24
℃
WB, outdoor temperature(heating): 7
℃
DB/6
℃
WB
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound
intensity meter. It is a sound pressure noise level. The detailed method please refer to the following information:
