Haier AP48KN1EAA - Specification

Single Split
2
2. Specication
Item Model
1U48IN1EAB/AP48KN1EAA(
H）
Function
cooling heating
Capacity BTU/h
48000 51500
Capacity kW
14.1
15.1
Sensible heat ratio
Rated power input KW
4.9 5.1
Max. power input KW
6.2 8.6
EER or COP W/W
2.85
2.95
Dehumidifying capacity 10
‐
³×m³/h
5
Power cable section
5G×4.0mm
2
Signal cable section
4G×2.5mm2
Connecting cable section
4G×2.5mm
2
Wired control cable
（
for wired control unit
）
section
/ /
Power source N, V, Hz
3, 380~415,50
Rated /Max.Running current A / A
9.0A/11.2A 9.2A/23.6A
Start Current A
62
Class of anti electric shock
CLASS I
Circuit breaker A
30
Max. operating pressure of heat side Mpa
4.15 4.15
Max. operating pressure of cold side Mpa
4.15 4.15
Indoor unit
Unit model (color)
AP48KN1EAA
（
H
）
Fan
Type × Number
centrifugal*1
Speed(H-M-L) r/min
430/400/370
Fan motor output
power
kW
0.09
Air-ow(H-M-L) m³/h
1800
Heat exchanger
Type / Diameter mm
inner grooved pipe/φ7
Total Area m²
0.45
Temp. scope
℃
/
Dimension
External
（
L×W×H
）
mm×mm×mm
1850/600/350
Package
（
L×W×H
）
mm×mm×mm
1980/660/420
Air sending angle
/
Drainage pipe (material , I.D./O.D.) mm
PVC 16/20
Control type (Remote /wired /model)
Remote
Fresh air hole dimension mm
/
Outlet distribution hole dimension mm
/
Electricity Heater kW
3
Noise level (H-M-L) dB(A)
51/48/44
Weight (Net / Shipping) kg / kg
60/71
