Haier AP48KN1EAA - Sensor Characteristic

Single Split
48
12.
Sensor characteristic
Model Name Code Characteristic
1U48IN1EAB/
AP48KN1EAA
Indoor
Ambient temp. sensor 001A3900159
R25=23KΩ±3%
B25/50=4200K±3%
Coil pipe temp. sensor 0010401922
R25=10KΩ±3%
B25/50=3700K±3%
Outdoor
Ambient temp. sensor 001A3900110
R25=5KΩ±3%
B25/50=3450K±1%
Discharge temp. sensor 0010450398
R80=50KΩ±3%
B25/80=4450K±3%
Coil pipe temp. sensor 0010451314
R25=5KΩ±3%
B25/50=3450K±3%
R25=10KΩ±3% B25/50=3700K±3%
T(
℃
) Rnom(KΩ) T(
℃
) Rnom(KΩ) T(
℃
) Rnom(KΩ) T(
℃
) Rnom(KΩ)
-20 90.79 6 23.27 31 7.83 56 3.11
-19 85.72 7 22.2 32 7.52 57 3.11
-18 80.96 8 21.18 33 7.23 58 2.9
-17 76.51 9 20.21 34 6.95 59 2.81
-16 72.33 10 19.3 35 6.68 60 2.72
-15 68.41 11 18.43 36 5.43 61 2.63
-14 64.73 12 17.61 37 5.6 62 2.54
-13 61.27 13 16.83 38 5.59 63 2.49
-12 58.02 14 16.09 39 5.73 64 2.38
-11 54.97 15 15.38 40 5.52 65 2.3
-10 52.1 16 14.71 41 5.32 66 2.23
-9 49.4 17 14.08 42 5.12 67 2.16
-8 46.86 18 13.48 43 4.93 68 2.09
-7 44.46 19 12.9 44 4.9 69 2.03
-6 42.21 20 12.36 45 4.58 70 1.96
-5 40.08 21 11.84 46 4.42 71 1.9
-4 38.08 22 11.34 47 4.26 72 1.85
-3 36.19 23 10.87 48 4.11 73 1.79
-2 34.41 24 10.43 49 3.97 74 1.73
-1 32.73 25 10 50 3.83 75 1.68
0 31.14 26 9.59 51 3.7 76 1.63
1 29.64 27 9.21 52 3.57 77 1.58
2 28.22 28 8.84 53 3.45 78 1.54
3 26.4 29 8.48 54 3.33 79 1.49
4 25.61 30 8.15 55 3.22 80 1.45
5 24.41
