Pipe specication:
a
a
a
a
b
b
c
1. Pipe "a" diameter (between indoor and branch pipe) (depends on indoor pipe)
2. Pipe "b" diameter (between branch pipes)
Total indoor capacity after the branch pipe (x100W) Gas pipe (mm) Liquid pipe (mm)
X<112 Ø15.88 Ø9.52
112≤X< 234 Ø19.05 Ø9.52
3. Pipe "c" diameter ( outdoor pipe diameter)
Note:
1.When the distance from outdoor to the longest indoor is over 30m, the main pipe should be the enlarged
diameter.
2. If pipe b diameter is larger than main pipe c, enlarge main pipe c diameter to be the same as pipe b.
Outdoor model
Standard pipe diameter Enlarged pipe diameter
Gas pipe (mm) Liquid pipe (mm) Gas pipe (mm) Liquid pipe (mm)
AU04 Ø15.88 Ø9.52 Ø19.05 Ø12.7
AU05 Ø15.88 Ø9.52 Ø19.05 Ø12.7
AU06 Ø15.88 Ø9.52 Ø19.05 Ø12.7
Drain pipe disposal
• Make sure the drain works properly.
• In regions where buildups of snow can be expected, the accumulation and freezing of snow in the space between
the heat exchanger and external plate may lower operating efciency.
• After punching the knock-out hole, the application of repair-type paint on the surface around the edge sections is
recommended to prevent rust.
1. Pipe a (indoor-branch pipe) diameter: decided by connected indoor capacity
Indoor rated capacity
(x100w)
Gas pipe Liquid pipe Note
22~28 9.52 6.35
AS07/092MGERA gas pipe should be 12.7
AS182MGERA gas / liquid pipe should be 15.88 / 9.52
36~56 12.7 6.35
71~140 15.88 9.52
226~300 25.4 9.52
450~600 28.58 12.7
(1) When pipe length between indoor & nearest branch pipe ≥15m, adjust in accordance with following criteria:
①
If indoor rated capacity≤5.6kW, change gas / liquid pipe diameter to 15.88 / 9.52
②
If 16.8kW≥ indoor rated capacity>5.6kW, change gas / liquid pipe diameter to 19.05 / 9.52
③
If indoor rated capacity>16.8kW, change liquid pipe diameter to 12.7
