Outdoor power source and power cable
Item
Model
Power
source
Power cable
section
(mm
2
)
Circuit
breaker
(A)
Rated current of residual
circuit breaker (A)
Ground fault interruptor (mA)
response time (S)
Ground wire
Section
(mm
2
)
Screw
Individual power
AU042FPERA
1PH,
220-230V~,
50/60Hz
10 50 50A 30mA below 0.1S 10 M5
AU052FPERA 10 50 50A 30mA below 0.1S 10 M5
AU062FPERA 10 50 50A 30mA below 0.1S 10 M5
AU04IFPERA
3N~,
380-400V,
50/60Hz
4 20 20A 30mA below 0.1S 4 M5
AU05IFPERA 4 20 20A 30mA below 0.1S 4 M5
AU06IFPERA 4 20 20A 30mA below 0.1S 4 M5
• Power cable must be xed rmly.
• Each outdoor must be earthed well.
• When power cable exceeds the range, thicken it appropriately.
Indoor power source and communication wiring
Item
Indoor
total
current (A)
Power
cable
section
(mm
2
)
Wire
length
(m)
Rated current
of overcurrent
breaker
(A)
Rated current of residual
circuit breaker(A)
Ground fault interruptor(mA)
response time(S)
Communication wire section
Outdoor/indoor
(mm
2
)
Indoor/indoor
(mm
2
)
<10 2 23 20 20A, 30mA, below 0.1s
2-core × (0.75-2.0mm
2
)
shielded wire
≥10 and <15 3.5 24 30 30A, 30mA, below 0.1s
≥15 and <22 5.5 27 40 40A, 30mA, below 0.1s
≥22 and <27 10 42 50 50A, 30mA, below 0.1s
• Power cable and communication wire must be xed rmly.
• Each indoor must be grounded well.
• When power cable exceeds the range, increase the gauge appropriately.
• Shielded layer of communication wires must be connected together and be earthed at single
point.
• The total length of communication wire cannot exceed 1000m.
Communication wire for wired controller
Wire length(m) Wire spec Wire length(m) Wire spec
<100 0.3mm
2
×(3-core) shielded wire ≥300 and <400 1.25mm
2
×(3-core) shielded wire
≥100 and <200 0.5mm
2
×(3-core) shielded wire ≥400 and <600 2mm
2
×(3-core) shielded wire
≥200 and <300 0.75mm
2
×(3-core) shielded wire
• Shielded layer of communication wire must be grounded at one end.
• The total length cannot exceed 600m.
