plug (direct connection to the mains) or the plug is not
located in an accessible area, even after installation, apply
a standard double pole switch that ensures complete
disconnection from the mains in category III overvoltage
conditions, in accordance with the installation rules. •The
product features a special power cable; if the cable is
damaged, contact the Service Centre for a replacement.
● Please note! Before reconnecting the circuit to the
mains power supply and making sure that it is working cor-
rectly, always check that the power cable is correctly in-
stalled.
Please note! Do not use with a programmer, timer, separ-
ate remote control or any other device that activates auto-
matically.
RECOMMENDATIONS FOR USE
Recommendations for correct use in order to reduce the
impact on the environment: When cooking begins, the
device should be turned on at minimum speed, and left on
for a few minutes even after cooking is complete. Increase
the speed only if there is a large quantity of fumes and
steam, using the Booster function only in extreme cases.
To keep the odour reduction system running efficiently, re-
place the carbon filter/s when necessary. To ensure the
high performance of the grease filter, clean it when neces-
sary. To improve efficiency and minimise noise, use the
maximum duct diameter indicated in this manual.
END-OF-LIFE DISPOSAL
This appliance is labelled in accordance with the
European Directive 2012/19/EU on Waste Elec-
trical and Electronic Equipment (WEEE).
WEEE contains both pollutants (which can have a negative
effect on the environment) and basic elements (which can
be reused).
It is important that WEEE is subject to specific treatment to
remove and properly dispose of pollutants and to recover
all the materials. Individual citizens can play an important
role in ensuring that WEEE does not become an
environmental problem; it is essential to follow some basic
rules:
- WEEE must not be treated as household waste;
- WEEE must be taken to collection centres managed by
the municipality or by a registered company.
In many countries, household collection may be available
for large WEEE. When a new appliance is purchased, the
old one can be given to the seller who must accept it, free
of charge, as a single piece, provided that the appliance is
of an equivalent type and has the same functions as the
one purchased.
REGULATIONS
Equipment designed, tested and manufactured in
compliance with safety regulations: EN/IEC 60335-1; EN/
IEC 60335-2- 31, EN/IEC 62233. Performance: EN/IEC
61591; ISO 5167-1; ISO 5167-3; ISO 5168; EN/IEC
60704-1; EN/IEC 60704-2-13;EN/IEC 60704-3; ISO 3741;
EN 50564; IEC 62301. EMC: EN 55014-1; CISPR 14-1; EN
55014-2; CISPR 14-2; EN/IEC 61000-3-2; EN/IEC
61000-3-3.
USE
The extraction system can be used in the duct-out version
with external evacuation, or in the recirculating version with
filtering and internal recirculation.
● Duct-Out Version:
Vapours are evacuated outside through an exhaust pipe at-
tached to the connecting flange.
CAUTION! If the product features one or more carbon fil-
ters, they must be removed.
Connect the product to wall-mounted exhaust pipes and
holes with a diameter equivalent to the air outlet (connect-
ing flange).
The use of pipes and outlet holes in the wall with a smaller
diameter will reduce the extraction performance and
drastically increase the noise level.
All responsibility in this regard is therefore denied.
• Use a ducting pipe with the shortest length necessary.
• Use a ducting pipe with the least number of bends pos-
sible (maximum bend angle: 90°).
• Avoid drastic changes in the ducting pipe diameter.
● Recirculating Version:
The suctioned air will be degreased and deodorised before
it is sent back into the room. To use the product in this ver-
sion, it is necessary to install an additional activated carbon
filter system.
ASSEMBLY BEFORE INSTALLATION
• Check that the product is the right size for the installation
area.
• Remove the activated carbon filter(s) if supplied (see also
relevant paragraph).
• It(they) must be reinstalled if the product is used in the fil-
ter version.
• If there are panels and/or walls and/or wall units on the
sides, make sure that there is enough space to install the
product and that it is always possible to access the control
panel easily.
• The product is equipped with fixing plugs suitable for most
walls/ceilings. However, it is necessary to consult a quali-
fied technician to make sure that the materials are suitable
for the type of wall/ceiling. The wall/ceiling must be strong
enough to support the weight of the hood.
Heavy product, two or more people are required for
handling and installation operations.
7
