DISASSEMBLY
Removing & Replacing Freezer Door Handle
Get 2 fasteners out of the accessory bag and place them in 2 reserved holes in the freezer
door. Install a handle by attaching the reinforcing plate to the fasteners and then pushing the
handle leftwards into its place. To remove the handle, push it rightwards.
Fastener
Reinforcing plate
5. Installing wine shelf
Open the door of refrigerator compartment. Take out the food shelf at the upper left corner. Place
the glass shelf downward on a table. Then take out the wine shelf from the delicatessen drawer
at the bottom. Hold the wine shelf at both ends, attach it to the food shelf (as shown below in Fig 1)
and then push it in place (as shown below in Fig 3).
ı
ı
6. Installing front cover of delicatessen drawer
Open the door of refrigerator compartment. Take out the front cover of delicatessen drawer from the
crisper cover. Then place the rotary shaft at both ends of the delicatessen drawer into the supporting
slot of the slide guide, and turn the front cover of delicatessen drawer down.
