DISASSEMBLY
ĹRemove the door and place it in a proper
position.
ĺRemove the middle hinge if necessary.
ĻReplace the door in a reverse sequence
of removal.
3. Removing & Replacing Freezer Drawer
ķPull out the freezer drawer entirely and
remove it from the refrigerator.
ĸRelease the buckles on both sides and pull out
the drawer door in the direction shown on the
slideway and remove it from the refrigerator.
Ĺ Replace the freezer drawer in a reversal sequence to removal.
4. Removing & Replacing Door Handle
Take out the door handles from the refrigerator compartment (2 longer handles to be installed on
the refrigerator and 1 shorter handle to be installed on the freezer). The following instructions
should be observed.
Removing & Replacing Refrigerator Door Handle
Get 2 fasteners out of the accessory bag and place them in 2 reserved holes in the left door.
Install a handle by attaching the reinforcing plate to the fasteners and then pushing the handle
downwards into its place. Install the right handle in the same way. To remove the handle, push it
upwards.
Fig 1
Fastener
Reinforcing plate
To Next Page
