Haier HL42XK1 User Manual

cover indicated with blue line.
Remove the four screw from the rear
4-1 Remove the Pedestal 4-3.
ķ /D\GRZQWKHXQLWVRWKDWUHDU
FRYHUIDFHVXSZDUG
ĸ

Ĺ 7KHQUHPRYHWKHSHGHVWDO
4-2Remove the Back Cover
ķ Remove the seventeen screw indicated
on figure above by blue line.
ĸ Then remove the back cover from the
unit.
Remove the two screw from the speaker indicated
on figure above by blue line.
4-4 Remove the Terminal Bracket
ķ Remove the six screw indicated on the
figure above by blue line.
ĸ Then put the terminal bracket to the side
Remove the speaker

Haier HL42XK1 Specifications

General

Brand	Haier
Model	HL42XK1
Category	TV
Language	English
