46
State
˖
No picture
Fail
Pass
Fail
Pass
Fail
Pass
Fail
Pass
No Raster on Panel
Check the backlight B/D
Change the backlight B/D
Check the input/output of
jack CN3 of Main B/D
Re-soldering or change
IC UA1 and RNA1-17
Check the input/output of
Jack CN4 of Main B/D
Re-soldering or change
IC U13
Change the panel
Change the Panel wire
Check the Panel wire
