Haier hlp140e Service Manual

Troubleshooting diagram
Check there's power supply,
and if the power cord is reliably connected
with the power supply?
Drum does not rotate and heat
Is the drying
time more than 300
minutes?
It heats but the drum does not rotate
Yes
No
No
Yes
Check if the wedge belt is broken
Check if tension pulley, spring
and motor are installed in place
Re-install tension pulley,
spring and motor, and
manually turn the drum
Replace the wedge belt
Connect the power and close the door
Yes
Check if the motor is OK
Yes
Check if the wire
module is OK
Replace the motor
No
Check if the capacitor is OK
Replace the capacitor
No
Yes
MAINTENANCE SERVICE AND TROUBLE SHOOTING
15
Tumble Exhaust Type Clothes Dryer
Model:HLP140E
Check the drying time '150'
'90' '60' flash at the same time
No
No
Yes
Protective program,
put the power on again
Adjust or change the
temperature sensor
Adjust or change the door switch
Yes
Check if the wire module is ok
Yes
Connect the power resource
No
Are the lights of the cycle
flash at the same time
Yes
No

Haier hlp140e Specifications

General

AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption	- kWh
Energy efficiency class	-
Annual energy consumption	400 kWh
Door hinge	Left
Drum volume	73.62 L
Control type	Touch
Loading type	Front-load
Product color	White
Built-in display	No
Appliance placement	Freestanding
Cycle time	150 min
Drum capacity	2.6 kg
Number of cycles	4
Package depth	482.6 mm
Package width	722.2 mm
Package height	780 mm
Package weight	28123 g
LED program stage indicator	Yes

Weight and Dimensions

Depth	425 mm
Width	630 mm
Height	685 mm
Weight	24766 g
