Product introduction and main features
3. Exhaust portion
The air from the drum is exhausted through the air outlet grill, filter screen, air impeller and
the exhaust duct. The exhaust direction can be altered by adding an exhaust pipe.
4. Door and control panel structure
The door lock adopts a drawing structure which can be opened by pulling the door handle.
The door switch is installed between the front panel and drum supporter. The projecting arm
at middle part of the door projects or releases the link lever of the door switch to connect or
disconnect the door switch.
The operation is easy and simple. The door switch is installed between the front panel and
the drum supporter. It is safe enough.
I. Product introduction
1. Air inlet structure
In the air inlet portion left lower of the dryer there's a PTC heating device, through which the air
is guided from the air inlet into the drum by rotation of the dryer drum and impeller driven by the
motor. The heating device is a positive temperature coefficient (PTC) semi-conductor heater of
self-control of temperature and high safety provided with a 70 thermo-limiter.
At the air inlet a filter screen is provided to keep air clean and free of impurities.
2. Drum portion
The support plate front of the drum is installed on the dryer cabinet with 6 connectors. A white
felt and a wear-resistant tetrafluoroethylene wearing piece are attached on the drum support
plate. The drum front and rear sealing is made with felt. The drum rear part is mounted with
nuts on the shaft rivetted on the drum support bracket where the air impeller and antiwear
spacer are installed.
The air outlet filter screen is installed in the drum. Take care the filter fixed on the drum with
screws shall be carefully cleaned when cleaning the filter screen.
Antibacterial drying, easy and safe
PTC heating, rapid temperature rise
Automatic thermo-limiting, safe and easy
No outdoor air drying, avoiding dust pollution
Computerised control auto drying
2
Tumble Exhaust Type Clothes Dryer
Model:HLP140E
