DISMANTLE THE TRANSPORTATION BOLTS
The transportation bolts are designed for clamping anti-vibration components
inside of the washing machine during the transportation process.
Remove the back cover.1.
Remove the three bolts on the rear side and take out the synthetic 2.
stabilisers from within the machine.
Replace the back cover.3.
Fill the holes left by the bolts with blanking plugs.4.
ADJUSTING THE WASHING MACHINE
There are adjustable feet under the bottom of the washing machine. Before use, they should be adjusted
so that the machine is level. This will minimise vibrations and thus noise during use. It will also reduce wear
and tear. We recommend using a spirit level to level the appliance.The fl oor should be as stable and fl at as
possible.
PASTE THE FELTS AND INSTALL THE CALCIUM-PLASTIC BOARD
1.Paste the felts on any side of the calcium-plastic board(figure 1.)
2.Put down the machine backwards, Remove the four screws (figure 2.)
3.Put on the calcium-plastic board which the side with felts is
inward, then install the screws which go across the four holes on
the calcium-plastic board (figure 3). Finally keep the machine upright.
1.
3.
2.
When opening the shrink package, you will find a calcium-plastic board and a felt. They are
used for reducing noise after covering the bottom of the cabinet.
fig.5
Note:
2.When you replace the back cover, the convexity must face
to outside, and you have to insert the back cover from the
1.Please pull out the power plug before removing the
transportion bolts.
two gaps as shown in fig.5.
3.Keep the transportation bolts and synthetic stabilisers
in a safe place for later use.
