Haier HW70-B12636N User Manual

GB
2-Product description
7
2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.2-3):
Inlet hose-
assembly
5 Blanking
plugs
Drain hose
bracket
User manual
Warranty-card
Note:
-
2-3
1
3
4
2
6
7
5
T1
T2
T3
S1
S2
S6
S4
T4
1
3
4
2
65
1 Detergent /Softener drawer
2 Worktop
3 Programme selector
4 Panel
1 Transportation bolts (T1-T4)
2 Back cover
3 Back cover screws (S1-S6)
4 Power cord
5 Water inlet valve
6 Drain hose
2-1
2-2
5 Rating plate
6 Service flap
7 Adjustable feet
S3
S5
2x
2x
Noise
reduction pads

Haier HW70-B12636N Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Drum volume	45 L
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Illumination color	Amber
Appliance placement	Freestanding
Drum capacity	7 kg
Cycle time (max)	206 min
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1200 RPM
Noise level (spin)	67 dB
Number of washing programs	16
Add garment (pause) function	No
Annual water consumption washing	9000 L
Annual energy consumption washing	106 kWh
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	41 L
Energy consumption washing per cycle	- kWh
Package depth	565 mm
Package width	650 mm
Package height	890 mm
Package weight	70000 g

Weight and Dimensions

Depth	510 mm
Width	590 mm
Height	850 mm
Weight	64000 g
