Haier HW80-B1439N User Manual

EN
2-Product description
7
Note:
-
2.1 Picture of appliance
1. Detergent / Softener drawer
2. Programme selector
3. Worktop
4. Display
5. Rating plate
6.
7. Adjustable feet
1. Transportation bolts (T1-T4)
2. Back cover
3. Back cover screws (S1-S6)
4. Power cord
5. Water inlet valve
6. Drain hose
2.2 Accessories
Check the accessories and literature in occordance with this list (Fig.: 2-3).
Inlet hose-
assembly
5 Blanking
plugs
Drain hose
bracket
Warranty
card
2-3
1400
rpm Capacity
7kg
+++
A
Energy
Speed up
HW70-BP1439
Temp.
Speed Start/pauseExtra rinse DelaySteam
Cotton
Synthetics
Mix
Sportwear
Jeans
Baby clothes
Cotton+
Hygienic
Fast wash
Spin
Bedding
Handwash
Delicate
Daily Wash
Quick 15”
Wool
2 3
5
6
7
41
T1
T2
T3
S1
S2
S6
S4
T4
1
2 3 4 5 6
S3
S5
Noise red-
uction pads

Haier HW80-B1439N Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Illumination color	Amber
Appliance placement	Freestanding
Drum capacity	8 kg
Cycle time (max)	245 min
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	67 dB
Noise level (wash)	53 dB
Number of washing programs	16
Add garment (pause) function	No
Cycle time (quick washing program)	15 min
Current	10 A
Connected load	2000 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.38 W
Power consumption (standby)	0.5 W
Energy consumption washing per cycle	- kWh
Package width	650 mm
Package height	890 mm
Package weight	75000 g

Weight and Dimensions

Depth	550 mm
Width	590 mm
Height	850 mm
Weight	72000 g
Door diameter	320 mm
