Haier HW80-B1439N User Manual

3-Control panel
Note : Acoustic signal
In following cases an acoustic signal sounds:
▶ when pressing a button
▶ when turning the programme selector
▶ at the end of programme
▶ in case of failures
Press this button (Fig. 3-1) gently to switch on, the dis-
play is shining, the indicator of the “Start/Pause” button
a while machine will shut down automatically.
3.2 Programme selector
By turning the knob (Fig. 3-2) one of 16 programmes
can be selected .
3.3 Display
The display (Fig. 3-3) shows following information:
▶ Washing time
▶ End time delay
▶ Error codes and service information
3-1
3-2
3
10kg
Capacityrpm
Speed up
Temp.
Speed Start/pauseExtra rinse DelaySteam
Cotton
Synthetic
Mix
Underwear
Cotton 20°C
Baby Care
Eco 40-60
Hygiene
Fast
Spin
Duvet
Jeans
Delicate/silk
Sport
Express 15min
Wool
HW100-B1439N
1400
2
EN
8
3-3
“ ”
“ ”
“ ”

Haier HW80-B1439N Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Water fill	Cold
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Tub material	Plastic
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Custom panel-ready	-
Illumination color	Amber
Appliance placement	Freestanding
Drum capacity	8 kg
Cycle time (max)	245 min
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	67 dB
Noise level (wash)	53 dB
Number of washing programs	16
Add garment (pause) function	No
Cycle time (quick washing program)	15 min
Current	10 A
Connected load	2000 W
Power plug type	Type F (CEE 7/4)
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.38 W
Power consumption (standby)	0.5 W
Energy consumption washing per cycle	- kWh
Package width	650 mm
Package height	890 mm
Package weight	75000 g

Weight and Dimensions

Depth	550 mm
Width	590 mm
Height	850 mm
Weight	72000 g
Door diameter	320 mm
