Haier HW80-B1486 User Manual

12
APPLIAN
C
EU
S
IN
G
THE
PROGRAM SELECTION
QUICK START GUIDE
1.Open door and put laundry in drum, checking that there are no coin, clips, paper tissues or sharp objects in the clothing
2.If using liquid detergent place the detergent in the manufactures recommended container in the drum. Note. Do not use the
auto weigh function with liquid detergent, it may spoil the cloths.
3.Open soap drawer and fill with soap powder and fabric conditioner as required. Do not use more than the manufactures
recommended amount.
4.Close the door
5.Turn on water and electrical power, if not already on.
6.Press the Power button to switch on the washing machine
7.Select the wash program by turning program knob or press Memo button if ‘custom wash’ has been previously saved.
8.If selecting Cotton, Synthetic or Mix wash programs, the washing machine default to the AUTO weigh program. If auto weigh
is not required, e.g. using liquid detergent, press the Wash or Rinse or Spin buttons to cancel the auto weigh function.
9.Change temperature, spin speed, spin duration any delayed start etc. as required, see “BUTTON OPERATION FUNCTIONS”
section of this manual for details.
10.Press Start/Pause button to start the wash program.

Haier HW80-B1486 Specifications

General

Current	10 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (typical)	2000 W
Water consumption per cycle	- L
Energy consumption washing per cycle	- kWh
Washing class	A
Annual water consumption washing	11440 L
Annual energy consumption washing	186 kWh
Display type	LCD
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Inverter technology	No
Drum capacity	8 kg
Delay start (max)	24 h
Spin-drying class	B
Maximum spin speed	1400 RPM
Noise level (spin)	74 dB
Noise level (wash)	53 dB
Number of washing programs	12
Package weight	78000 g

Weight and Dimensions

Depth	650 mm
Width	595 mm
Height	850 mm
Weight	74000 g
