2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.2-3):
Note:
1 Detergent/Softener drawer
2
Control panel
3
Worktop
4 Door
5 Filter cover
6 Adjustable feet
1 Transportation bolts (T1-T4)
2 Backcover
Backcover screws (7 EA)
3
4 Power cord
5
Water inlet valve
6
Drain hose
2-1 2-2
2-3
2-Product description
Inlet hose
assembly
5 Blanking
plugs
Drain hose
bracket
User manual
Due to technical changes and different models,the illustrations in the following ch-
apters may differ from your model.
