21
6. Remote control malfunction
Remote Control malfunction
Replace the battery
Replace the remote control
Whether the IR board is
abnormal?
Ye
s
No
Replace the IR board
Replace the main board
No
Ye
s
No
Ye
s
Use the other remote controls
Check the remote control
battery is
not properly placed or no powe
r?
20
22
Table of Contents
Table of Contents
1
Important Safety Notice
2
Revision List
3
General Specification
4
Operating Instructions
5
Input/Output Specification
9
Mechanical Instructions
12
Repair Flow Chart
16
PCB Layout
23
Main Board
23
Power Board
27
Key Board
30
IR Board
30
LED Board
31
Adjustment
32
WB Adjustment
32
FW Upgrade
33
The Writing VGA & HDMI EDID
38
Block Diagram
43
Wiring Diagram
45
Schematic Diagram
46
Main Board
46
Power Board
59
Key Board
61
IR Board
62
LED Board
63
