38
7.3 The Writing VGA & HDMI EDID
Step1. Ready for writing EDID
T
ool: 715G2005-C2
Cable: a LPT cabl
e, a VGA
cable, a DVI to HDMI cable and a 12V DC adapter
.
715G2005-C2
male
to
male
LPT
cable
V
G
A
c
a
b
l
e
D
V
I
t
o
H
D
M
I
c
a
b
l
e
Step2. Connection for writing VGA
EDI
D. (TV
AC on)
Note: T
ake L32F6 DDC SOP
for example.
Co
nn
ect
to
P
C
LPT
po
r
t
.
Connect to TV VGA
port.
12V DC input
37
39
