163
SW1 sets the communication address between the valve box and the indoor unit 1.
SW2 sets the communication address between the valve box and the indoor unit 2.
SW3 sets the communication address between the valve box and the indoor unit 3.
SW4 sets the communication address between the valve box and the indoor unit 4.
The setting method of each dip switch is the same. Take SW1 as an example
SW1_1
Manner of set
address
OFF Set the address with automatism
（
default
）
ON Set the address with dip switch
SW1_2 Pre-set
OFF Pre-set
（
default
）
ON Pre-set
SW1_3
~
SW1_8
Set the
communication
address with dip
switch
[3] [4] [5] [6] [7] [8] Communication address
OFF OFF OFF OFF OFF OFF 0#
（
default
）
OFF OFF OFF OFF OFF ON 1#
OFF OFF OFF OFF ON OFF 2#
OFF OFF OFF OFF ON ON 3#
OFF OFF OFF ON OFF OFF 4#
OFF OFF OFF ON OFF ON 5#
OFF OFF OFF ON ON OFF 6#
OFF OFF OFF ON ON ON 7#
OFF OFF ON OFF OFF OFF 8#
OFF OFF ON OFF OFF ON 9#
OFF OFF ON OFF ON OFF 10#
OFF OFF ON OFF ON ON 11#
OFF OFF ON ON OFF OFF 12#
OFF OFF ON ON OFF ON 13#
OFF OFF ON ON ON OFF 14#
OFF OFF ON ON ON ON 15#
OFF ON OFF OFF OFF OFF 16#
OFF ON OFF OFF OFF ON 17#
OFF ON OFF OFF ON OFF 18#
OFF ON OFF OFF ON ON 19#
OFF ON OFF ON OFF OFF 20#
OFF ON OFF ON OFF ON 21#
OFF ON OFF ON ON OFF 22#
OFF ON OFF ON ON ON 23#
OFF ON ON OFF OFF OFF 24#
OFF ON ON OFF OFF ON 25#
OFF ON ON OFF ON OFF 26#
OFF ON ON OFF ON ON 27#
OFF ON ON ON OFF OFF 28#
OFF ON ON ON OFF ON 29#
OFF ON ON ON ON OFF 30#
OFF ON ON ON ON ON 31#
ON OFF OFF OFF OFF OFF 32#
ON OFF OFF OFF OFF ON 33#
ON OFF OFF OFF ON OFF 34#
ON OFF OFF OFF ON ON 35#
