164
SW03_3
~
SW03_8
Set the
communication
address with dip
switch
[3] [4] [5] [6] [7] [8] Communication address
ON OFF OFF ON OFF OFF 36#
ON OFF OFF ON OFF ON 37#
ON OFF OFF ON ON OFF 38#
ON OFF OFF ON ON ON 39#
ON OFF ON OFF OFF OFF 40#
ON OFF ON OFF OFF ON 41#
ON OFF ON OFF ON OFF 42#
ON OFF ON OFF ON ON 43#
ON OFF ON ON OFF OFF 44#
ON OFF ON ON OFF ON 45#
ON OFF ON ON ON OFF 46#
ON OFF ON ON ON ON 47#
ON ON OFF OFF OFF OFF 48#
ON ON OFF OFF OFF ON 49#
ON ON OFF OFF ON OFF 50#
ON ON OFF OFF ON ON 51#
ON ON OFF ON OFF OFF 52#
ON ON OFF ON OFF ON 53#
ON ON OFF ON ON OFF 54#
ON ON OFF ON ON ON 55#
ON ON ON OFF OFF OFF 56#
ON ON ON OFF OFF ON 57#
ON ON ON OFF ON OFF 58#
ON ON ON OFF ON ON 59#
ON ON ON ON OFF OFF 60#
ON ON ON ON OFF ON 61#
ON ON ON ON ON OFF 62#
ON ON ON ON ON ON 63#
Notes:
The communication address setting is written in the chip during energization of the valve box
1) Make sure that the communication address code is set before the valve box is energized.
2) Be sure to close the cover of the electrical cabinet after setting.
