Haiwell PLC User Manual

en.haiwell.com Haiwell PLC -- Load Cell Module User Manual
7 / 24
Step 6: CR26H Writes value 2 to end the calibration process
27H
Low bytes of base weight of weights in channel 1, paragraph 1
R/W
2000
28H
High bytes of base weight of weights in channel 1, paragraph 1
R/W
0
29H
Low bytes of base weight of weights in channel 1, paragraph 2
R/W
0
2AH
High bytes of base weight of weights in channel 1, paragraph 2
R/W
0
2BH
Low bytes of base weight of weights in channel 1, paragraph 3
R/W
0
2CH
High bytes of base weight of weights in channel 1, paragraph 3
R/W
0
2DH
Automatic peeling range of channel 1
R/W
0
2EH
Channel 1 Weight Upper Limit Low Bytes (32 Bit Display)
R/W
32767
2FH
Channel 1 Weight Upper Limit High Bytes (32Bit Display)
R/W
32767
30H~4FH
Reserve
R
0
50H
Channel 2 average weight
R
51H
Channel 2 status code:
bit0：no-load（zero point weight）
bit1：exceed the weight upper limit
bit2：stability of measurement value
bit3~15：reserved
R
52H
Channel 2 Real-time weight
R
53H
Channel 2 uses 32-bit display flags:
0: 16-bit weight display
1: 32-bit weight display
R/W32
54H~55H
Channel 2 Real-time Weight 32 Bit Value:
54H: 32-bit low byte
55H: 32-bit high byte
R
56H~57H
The average weight of channel 2 is 32 bits:
56H: 32-bit low byte
57H:32-bit high byte
58H
Channel 2 Skin Weight Low Bytes
R/W
0
16 bits only use 58H, 32
bits use 58H 59H.
59H
Channel 2 Skin Weight High Bytes
R/W
0
5AH
Channel 2 Control Setting
Bit 0: Reservation
Bit 1: Gross/Net Weight Display, 0-Gross Weight, 1-Net Weight
Bit2-15: Reservation
R/W
0
Switch the current
display weight to wool
Weight or net weight,
used in calculation the
value of 58H and 59H as
tare weight
5BH
Channel 2 sampling frequency 0-7.5Hz，1-15Hz，2-30Hz，
3-60Hz，4-120Hz,5-240Hz，6-480Hz，7-960Hz
R/W
3
range：0~7
5CH-5DH
Reserved
R
5EH
Channel 2 average number of times
R/W
10
range：1~100
5FH
Channel 2 filter ratio
R/W
2
range：0~5
60H
Channel 2 standstill checking times
R/W
5
range：0~500
61H
Channel 2 standtill checking range
R/W
2
range：0~10000
62H
Channel 2 zero tracking intensity
0 :close zero tracking function
others: show zero tracking intensity(absolute value)
R/W
0
Abolute vaule,range ：
0~200
63H
Channel 2 zero-point detection range
R/W
10
Abolute vaule,range ：
0~10000
64H
Channel 2 weight upper limit
Set the upper limit value of weight, when measurement value is
over the set value will record error code
R/W
32767
65H
Channel 2 Skin Weight Read (Settings)
When 16-bit display, read the current weight value (50H) as the
weight value of the leather weight and store it at 58H.
When 32-bit display, read CR56H and CR57H as skin weight Z
value and store them at 58H and 59H.
R/W
0
0: no operation
1: Read the weight value
as the tare weight and
store it at 58H 59H.
Others: Invalid
