ENGLISH -
6
4.1 ASSEMBLING THE
COMPONENTS
4.1.a - Mounting the brush (Fig. 6)
- Lift the machine on vertically as shown in
the figure.
- Insert the brush (9) by inserting it in the
axle (24), then turn it until it is secured in
the holder (25) and a “click” is heard.
- Reposition the machine on the ground.
WARNING:
Use only brushes provided by the manufac-
turer according to the model of the machine.
Using other types of brushes may com-
promise the safety of the machine.
4.1.b - Positioning of the handle (Fig.
7)
- Unlock the handle (1) pulling the lever (3)
and lift it placing it in the desired position.
4.1.c - Battery mounting for the bat-
tery version only (Fig. 8a)
- Insert the battery (6) in the socket (26)
completely and then turn it towards the
machine until a click is heard.
4.1.d - Charger mounting for the elec-
tric version only (Fig. 8)
- Check if the power supply cable (23) is
correctly inserted in the charger (22).
- Insert the charger (22) in the socket (26)
completely and then turn it towards the
machine until a click is heard.
WARNING:
- The appliance must be powered via a
residual current device (RCD) with a re-
sidual nominal current for use not ex-
ceeding 30 mA.
- Unwind the electric power cable com-
pletely before connecting it to the
mains socket.
- Use an electrical extension lead only
if in perfect condition; ensure that the
section is appropriate for the appliance
power rating.
- Never let the power cable run over
sharp edges and do not tread on it.
- The socket must be easily accessible.
- it is the end user’s responsibility to use
a cable with the following features:
• 3x1 mm2 1.5 m H05VV-F or H05V-
VH2-F for the version with battery
charger;
• 3x1 mm2 15.0m H05VV-F or H05V-
VH2-F for the version with power
supply unit and compliant with the
latest editions of the regulations:
• for the power supply cable IEC
60227-1;
• for the socket IEC 60320-1 (for
connection of the power supply
cable to the appliance);
• for the plug IEC 60884-1 (Euro-
pean market);
• for the plug BS 1363-1 (Saudi
Arabian market);
• for the plug AS/NZS 3112 (Aus-
tralian/New Zealand market).
5.1 CHARGING THE
BATTERY (Fig. 9)
(IF EQUIPPED)
WARNING:
The batteries can only be charged using
a battery charger: 18.0071.00 - 24V - 5A or
alternatively 7501180 - 24V - 10A.
DANGER:
Charge the batteries in well-ventilated ar-
eas which comply with standards in force
in the country of use.
For safety-related information, follow
what is described in chapter 1 of this
manual.
WARNING:
For information and warnings on the bat-
tery charger, please refer to the manual of
the battery charger enclosed herein.
