HALE HP200 - Page 11

USER OPERATION AND MAINTENANCE
HP SERIES
PORTABLE PUMPS
11
HP100 SERIES PERFORMANCE CURVE
HP200 SERIES PERFORMANCE CURVE
0 50 100 150 200
GPM
0
20
40
60
80
100
120
140
160
180
200
220
240
260
280
300
PSI
0 100 200 300 400 500 600 700
LITERS/MIN
0
2
4
6
8
10
12
14
16
18
20
BAR
0
50
100
150
200
250
300
350
400
450
500
550
600
650
FEET
CURVE NO.
E-1121
Hale Fire Pump Company
Conshohocken, Pa. 19428 USA
UNIT MODEL : HP100
INLET: 2 IN
OUTLET: 1-1/ 2 IN
CONDITIONS: STP
LIFT: 4 FT
2400 RPM
2800 RPM
3200 RPM
3600 RPM
2000 RPM
5 HP
10 HP
15 HP
20 HP
25 HP
1-12-94 JDR
TOTAL HEAD
FLOW
ELEVATION: SEA-LEVEL
ENGINE:
BRIGGS & STRATTON MODEL
VANGUARD 18 OHV
18 HP @ 4000 RPM
PERFORMANCE BASED ON
95% OF ENGINE
MANUFACTURER'S MAXIMUM
BRAKE HORSEPOWER
0 50 100 150 200 250
GPM
0
20
40
60
80
100
120
140
160
180
PSI
0 100 200 300 400 500 600 700 800 900
LITERS/MIN
0
2
4
6
8
10
12
BAR
0
50
100
150
200
250
300
350
400
FEET
CURVE NO.
E-1122
Hale Fire Pump Company
Conshohocken, Pa. 19428 USA
UNIT MODEL : HP200
INLET: 2-1/2 IN
OUTLET: 2-1/2 IN
CONDITIONS: STP
LIFT: 4 FT
2400 RPM
2800 RPM
3200 RPM
3600 RPM
4000 RPM
5 HP
10 HP
15 HP
20 HP
25 HP
1-12-94 JDR
TOTAL HEAD
FLOW
ELEVATION: SEA-LEVEL
ENGINE:
BRIGGS & STRATTON MODEL
VANGUARD 18 OHV
18 HP @ 4000 RPM
PERFORMANCE BASED ON
95% OF ENGINE
MANUFACTURER'S MAXIMUM
BRAKE HORSEPOWER
