Figure12/Figure13: Secure the base with four provided screws.
Figure6: Remove the rear light and pull out the wires
Fig.11 Fig.12
Figure15/Figure16: Wire connections and terminals must be sealed
and waterproof.
Figure17/Figure18/Figure19: Clamp the terminal tightly to make sure
they are sealed and waterproof.
Fig.13 Fig.14
Fig.15 Fig.16
Fig.17 Fig.18
-6-
