Oregon Harvester Chain Micro Chisel Part #18HX078E (404.080” / 2.0mm)
STEP ONE:
Position the log table in the home position. From the cab, this would be all the way to the left.
STEP TWO:
Hold Saw button down, temporarily run oil to machine while bar goes down.
STEP THREE:
While holding the saw down, lower bar to ¾ of the way down. Stop oil flow.
STEP FOUR:
SHUT SKID STEER MOTOR OFF.
STEP FIVE:
Loosen saw clamp bolts. See picture to right.
STEP SIX:
Loosen adjustment behind saw bar. See picture below.
STEP SEVEN:
Remove chain.
MOUNTING NEW CHAIN:
Reverse steps to mount new chain.
NOTE:
Chain requires a 7/32” file to sharpen.
