Accessories supplied: Line Cord, Operators Manual, HZ21 Adapter Plug
(N-plug with BNC socket) and Software for Windows on CD-ROM
Optional accessories:
HZ70 Opto-Interface (with optical fiber cable)
HZ520 Antenna
HZ530 Near Field Probe Set for EMI Diagnosis
1 GHz Spectrum Analyzer HM5014-2
Valid at 23 °C after a 30 minute warm-up period
Frequency Characteristics
Frequency Range:
0.15 MHz to 1.050 GHz
Stability:
±5 ppm
Ageing:
±1 ppm/year
Frequency Resolution:
1 kHz (6
1
⁄2 digit in readout)
Center Frequency Range:
0 to 1.050 GHz
LO Frequency Generation:
TCXO with DDS (Digital Frequency Synthesis)
Span Setting Range:
Zero Span and 1 MHz -1000 MHz
(1-2-5 Sequence)
Marker:
Frequency Resolution:
1 kHz, 6
1
⁄2 digit,
Amplitude Resolution:
0.4 dB, 3
1
⁄2 digit
Resolution Bandwidths
(RBW) @ 6dB:
1 MHz, 120 kHz and 9 kHz
Video Bandwidth (VBW):
4 kHz
Sweep Time
(automatic selection): 40 ms, 320 ms,1 s*)
Amplitude Characteristics (Marker Related) 150 kHz – 1 GHz
Measurement Range:
-100 dBm to +10 dBm
Scaling:
10 dB/div., 5 dB/div.
Display Range:
80 dB (10 dB/div.),
40 dB (5 dB/div.)
Amplitude Frequency Response
(at 10 dB Attn., Zero Span and
RBW 1 MHz, Signal – 20 dBm):
±3 dB
Display (CRT):
8 x10 division
Amplitude Scale:
logarithmic
Display units:
dBm
Input Attenuator Range:
0 - 40 dB (10 dB increments)
Input Attenuator Accuracy
rel. to 10 dB:
±2 dB
Max. Input Level (continuous)
40 dB attenuation:
+20 dBm (0.1 W)
0 dB attenuation:
+10 dBm
Max. DC Voltage:
±25 V
Max. Reference Level:
+10 dBm
Reference Level Accuracy rel.
to 500 MHz, 10 dB Attn., Zero
Span and RBW 1 MHz:
±1 dB
Min. Average Noise Level:
approx. -100 dBm (RBW 9 kHz)
Intermodulation Ratio
(3
rd
Order):
typical ›75 dBc (2 Signals: 200 MHz,
203 MHz, – 3 dB below Reference Level)
Harmonic Distortion Ratio
(2
nd
harm.):
typical › 75dBc (200MHz, Reference Level)
Bandwidth Dependent
Amplitude Error rel. to RBW
1 MHz and Zero Span:
±1 dB
Digitization Error:
±1 digit (0.4 dB) at 10 dB/div. scaling
(Average, Zero Span)
Inputs/Outputs
Measuring Input:
N socket
Input Impedance:
50 Ω
VSWR: (Attn. ≥ 10 dB)
typ. 1.5:1
Tracking Generator Output:
N-socket
Output Impedance:
50 Ω
Test Signal Output:
BNC socket
Frequency, Level:
48 MHz, -30 dBm (±2 dB)
Supply Voltage for Probes
(HZ 530):
6 V DC
Audio Output (phone):
3.5mm Ø jack
RS-232 Interface:
9-pin / Sub-D
Functions
Keyboard Input:
Center Frequency, Reference Level,
Tracking Generator Level
Rotary Encoder Input:
Center Frequency, Reference Level,
Marker, Tracking Generator Level
Max. Hold Detection:
Peak Value Acquisition
Quasi-Peak Detection:*
Quasi-Peak Valuation
Average:
Mean Value Acquisition
Ref. Spectrum Memory:
2 k x 8 bit
SAVE/RECALL:
Save and Recall of 10 Instrument Settings
AM demodulation
for audio
LOCAL:
RS-232 Remote Control OFF
Readout:
Display of various Measurement
Parameters
Tracking Generator
Frequency Range:
0.15 MHz to 1.050 GHz
Output Level:
–50 dBm to +1 dBm
Frequency Response (0.15 MHz – 1 GHz)
+1 dBm to -10 dBm:
±3 dB
-10.2 dBm to -50 dBm:
±4 dB
Digitization Error:
±1 digit (0.4 dB)
Spurious Outputs:
better than 20 dBc
General information
CRT:
D14-363GY, 8 x 10 cm with internal graticule
Acceleration Voltage:
approx. 2 kV
Trace Rotation:
adjustable on front panel
Ambient Temperature:
10°C to 40°C
Power Supply:
105-253 V, 50/60 Hz ±10 %, CAT II
Power Consumption:
approx. 35 W at 230V/50 Hz
Safety Class:
Safety Class I (EN61010-1)
Dimensions (W x H x D):
285 x 125 x 380 mm
Weight:
approx. 6.5 kg
*) in combination with software AS100E only~
