PART 10. PARTS BREAKDOWN
ITEM # PART DESCRIPTION PART NUMBER
1 PANEL FRONT DOOR EVO299-399HOT ASSY W/BEVEL WIN D116957
DOOR ASSY EVO599HOT FLAT WINDOW D109348
2 BURNER INL HW599 AIR/GAS D105610
3 PILOT SPARK ELECTRODE ASSEMBLY 79-599 KNURLED PLT 94318 A
4 GASKET 3-5/16 OD EPDM 60 DURO TUBE/BURNER D104184
5 BURNER DOOR HW79-599 D105611
6 BURNER PIPE HW599 70MM X 395MM D105609
7 INSULATION BURNER DOOR W/ SPARES MONO/DUO HAM D105632
8 SWITCH TEMP LIMIT BURNER DOOR D106936
9 GASKET BLO HW599 D104185
10 FLANGE FAN ADPT AMETEK 7.6 TO EBM RG175 D105630
11 GASKET 3.27 OD EPDM 70A HW179 GAS/AIR INL PIP D106935
12 BLOWER 7.6 240VAC HGH OUTPUT ENHANCED FAN D109384
13 FLANGE FAN ADPT INL 140-100MM DIA AMETEK 7.6 D105631
14 COVER VENTURI BURNER AIR/GAS MXG HW599 D105629
15 COUPLING RDCR 1/4X1/8 NPT 150 SS CF8 D106932
16 TRANSDUCER PRESS 1/4 MNPT 0-1/2 PSI D104963
SWITCH DIF PRESS M20 CONN CNDS HW79-599 (NOT SHOWN) D113636
17 BRACKET PROTECTION HW299-599 CS TB G30 BOILER CTRL D107939
18 DISPLAY BOILER BRD D107557
19 SWITCH RKR ON/OFF 20A 250V DPST D108302
20 PANEL DWR HW299-599 D107543
21 TRANSFORMER IGNIT D104904
22 STANDOFF HEX #4-40 X 3/4 SS 18-8 D104901
23 BOARD CTRL BOILER 2 DRIVERS D108471
24 SPACER RD #4 X 1/4 NYL D104899
25 EXCHANGER HEAT HW599 ASME W/ FAST CONN D105679
26 BRACKET HOLD DOWN HEAT EXCHANGER SS T304 HW299-599 D106928
27 PLUG HEX 1/8 BSPP SS CF8 HW79-199SIT M5 HI-LMT D121450
28 PLUG HEX 1/4 BSPP SS CF8 HW299-599 M5 HI-LMT D121451
29 DRAIN HOSE LOWER ASSY HW299-399 CDK 94201
HOSE 1 OD POLY CROSS LINKED D107853
30 EVO HW299-599 CNDS TRAP DRN D104204
31 GROMMET 2-1/2 NEOPRENE 3-1/2 HOLE D104277
32 PANEL SIDE HW299-399 LEFT D117663
PANEL SIDE HW299-399 RIGHT D117661
PANEL SIDE 599 LEFT D109597
PANEL SIDE 599 RIGHT D109598
33 PANEL TOP HW299-399 CS A1008 TB D110567
TOP PANEL ASSY HW299-399 D118981
HW599 EVO TOP PANEL D107647
HW599 PANEL TOP ASSY D110440
34 PANEL BTM 20GA CS 1010-1020 HW299-399 POWDER COAT D113884
To Next Page
