Hamilton Engineering EVO Plus Series User Manual

59
PART 10. PARTS BREAKDOWN
ITEM # PART DESCRIPTION PART NUMBER
PANEL SHEET METAL BOTTOM ASSEMBLY 299-399 JKB 94102 B
PANEL BTM 18GA CS A1008 TB HW599HOT PWDR COAT D108482
PANEL BTM ASSY HW599HOT D109370
35 CAP PROTECTION 0.48 ID PVC BLACK D108572
36 GROMMET SNAP IN 1/2 OD X 3/8 ID NYLON WHITE L D108574
37 GASKET 5.9 OD W/ CUT 299/599 AIR INLET D104186
38 DISK RDCR 3.2 ID X 4-1/2 DUCT FLG SS A268 AIR INL HW299-399 D113156
COLLAR DUCT 4 SS A268 D109372
39 DUCT FLG 4-1/2 SS A268 AIR INL HW299-399 D113155
COLLAR DUCT 5 SS A268 W/ HOSE CLAMP D109371
40 GASKET 8.067 OD SILICON FLUE GAS HW299-399 D113103
GASKET 7-1/2 OD SILICON FLUE GAS HW599 D104188
41 FLANGE 8.07 OD CS GALV FLUE GAS HW299-399 SPCL COAT PROC D114072
FLANGE FLUE 5.887 ID CS TB G90 HW599 D109123
42 THERMISTOR 1/4 MBSPP X 55 MM 10 KOHM NEGATIVE D104921
43 FLUE GAS OUTLET ASSEMBLY HW299-399 VNT 94101 A
FLUE GAS OUTLET ASSEMBLY HW599 VNT 94102 A
44 EVO299-399 DUO VLV NON-RTN D113615
EVO 599 DUO VLV NON-RTN D104923
45 GROMMET 1.875 OD SILICONE AIR VENT TUBE BLACK D104189
46 ROD TBE 0.54 X 9.73 SS MT304 HW299-599 AIR VENT D108337
47 VENT AIR 1/8 NPT AUTOMATIC BRS D104903
48 PANEL REAR EVO299-399HOT D114534
HW599 EVO REAR PANEL HC D108296
49 ROD TBE 8MM X 12.812 SS T303 M8-1.25 X 1.625 D114161
ROD TBE 8MM X 17 SS T303 M8-1.25 X 1.625 D110848
ROD TBE M8X1.25 24.25 SS T303 HW599 HEAT EX HOLD DOWN D108299
50 BRACKET HGR CS A1011 CS TB HW79-599 SPCR D103748
51 BRACKET HGR CS A1011 CS TB HW79-599 D103747
52 BRACKET CS TB G30 GAS VAL FRONT HW599 D107926
53 ADAPTER NYLON 1/4 FNPT X 3/16 BARB D104964
54 EVO PWR RELAY HOT CONTROLS D108684
55 O-RING 26MM X 3.5MM RBR D114528
O-RING 1.63 OD RBR HW399 D113610
O-RING 40MM X 4MM EPDM 60 DUROMETER D104578
56 CLIP FORK SS T304 HW299 ARM D113886
CLIP FORK SS T304 HW399 ARM D113885
CLIP FORK SS HW599 ARM D108335
57 THERMISTOR 1/8 NPT X 25 MM 10 KOHM NEGATIVE TEMP COEFFICIENT DUPLEX D104920
58 THERMISTOR 1/8 NPT X 25 MM 10 KOHM NEGATIVE T D104919
59 SWITCH FLOW 1/2 MNPT 1.09 V-10 FLAT PADDLE EVO399-599SIT (HW599.3 ONLY) D114073
60 TRANSDUCER PRESS 1/8 MNPT 0-150 PSI (HW599.2 QTY=2X, HW599.3 QTY=1X) D104961
61 ARM OUT EVO599 D104575
